Paper Cup Tube Compressive Strength Tester with Digital Display

Paper Cup Tube Compressive Strength Tester with Digital Display
Paper Cup Tube Compressive Strength Tester with Digital Display Paper Cup Tube Compressive Strength Tester with Digital Display

Gambar besar :  Paper Cup Tube Compressive Strength Tester with Digital Display

Detail produk:
Tempat asal: CINA
Nama merek: Haida
Sertifikasi: CE、ISO
Nomor model: 5099-hd
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 set
Harga: Dapat dinegosiasikan
Kemasan rincian: setiap set dilindungi dengan serat resin dan film PP, kemudian dimasukkan ke dalam kotak kayu yang k
Waktu pengiriman: 20 hari setelah pesanan dikonfirmasi
Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union, Moneygram
Menyediakan kemampuan: 300 set per bulan

Paper Cup Tube Compressive Strength Tester with Digital Display

Deskripsi
Fungsi: Tes Kompresi, Uji Kekuatan Kompresif Tabung Kertas, Tester Burst, Uji Tarik, Instrumen Pengujian Ker Nama: Tabung Kertas Tabung Kekuatan Kompresif Penguji, Instrumen Pengujian Kertas Kertas GSM Tester/ Burst
Menampilkan: LCD, Tampilan Digital Unit beralih: KGF, n. (Opsional), lbf
Mode tampilan: Tampilan LCD, Mode Digital Mode getaran: Bergerak maju mundur
Drive gerakan: sekrup bola dan motor servo Dukungan khusus: OEM ODM
Penggunaan: Instrumen pengujian kertas Fitur: Presisi tinggi, operasi mudah, kinerja yang andal
Pengontrol: PLC (Programmable Logic Controller) Tes jatuh: Sudut, tepi, permukaan sampel
Metode tampilan: Tampilan Digital Tampilan waktu: Untuk menampilkan waktu selama pengujian
Area AS: peralatan masak Kriteria Desain: EN71 ANSI, UL, ASTM ISTA
Sistem Kontrol: Kontrol Terprogram PLC Asal: CINA
Metode tes: Elektronik, mekanik, manual Berat: Dapat disesuaikan
Modus transmisi: Perangkat pneumatik + reducer + rilis Mode Pindai: garis tunggal
Menggunakan: Bahan kemasan
Menyoroti:

Tube Compressive Strength Tester

,

Digital Display Compressive Strength Tester

,

Paper Cup Tube Compressive Strength Tester

5099-HD Oxygen Transmission Rate Tester
Product Overview
This advanced oxygen transmission rate tester utilizes coulometric oxygen analysis sensors and isobaric test principles to provide high-efficiency oxygen permeability testing for materials with varying gas barrier properties. The system offers precise temperature, humidity, and flow rate control with exceptional test sensitivity and repeatability.
Key Attributes
Function Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Display LCD, Digital display with unit switching (Kgf, N, Lbf)
Control System PLC (Programmable Logic Controller)
Movement Drive Ball screw and servo motor
Vibration Mode Reciprocating
Design Standards EN71, ANSI, UL, ASTM, ISTA
Test Methods Electronic, mechanical, manual
Transmission Mode Pneumatic device + reducer + release
Technical Features
  • Three independent test chambers for simultaneous testing of different samples
  • Imported high-precision sensors ensure exceptional test accuracy
  • Advanced water bath temperature control system with wide temperature range
  • Independent control of upper/lower chambers and sensors for result accuracy
  • Sealed pipeline system reduces system errors for more precise results
  • Anti-leakage sample structure design for stable sealing
  • Multiple test modes (manual, proportional, cyclic) for various scenarios
  • Expandable USB interfaces and network ports for data access
  • Self-detection capabilities ensure continuous operational status
  • Power-off automatic save function prevents data loss
Technical Specifications
Measuring Range Film: 0.01-200cm³/m²*24h (conventional)
Container: 0.00025-1 cm³/pkg*24h (optional)
Resolution 0.001 cm³/m²•24h
Temperature Control 5°C to 85°C (±0.1°C accuracy)
Humidity Control 0% RH, 5%-90%RH, 100%RH (±1%RH accuracy)
Sample Capacity 1-3 pieces (independent data)
Transmission Area 50 cm²
Max Sample Thickness ≤3mm
Carrier Gas 99.999% high purity nitrogen (user-provided)
Dimensions 740mm (L) × 415mm (W) × 430mm (H)
Weight 50Kg
Power Supply AC 220V 50Hz
Compliance Standards
GB/T 19789, ISO 15105-2, ASTM D3985, ASTM F2622, ASTM F1927, JIS K7126-2, YBB 00082003
Applications
Ideal for oxygen permeability testing of films, sheets, paper, and packaging materials in food, pharmaceuticals, medical devices, cosmetics, photovoltaic electronics, and related industries.
Product Images
Paper Cup Tube Compressive Strength Tester with Digital Display 0 Paper Cup Tube Compressive Strength Tester with Digital Display 1 Paper Cup Tube Compressive Strength Tester with Digital Display 2
About Haida
Haida products are extensively utilized across diverse industries including paper goods, packaging, ink printing, adhesive tapes, bags, footwear, leather goods, environmental protection materials, toys & baby products, hardware, electronics, plastics, and rubber. They are equally suitable for all research institutions, quality inspection agencies, and academic fields. Our products comply with UL, ASTM, JIS, GB, and ISO standards.
