Standard and High-Definition Video Formats Charge / Discharge Battery Testing System for TV Testing

Gambar besar : Standard and High-Definition Video Formats Charge / Discharge Battery Testing System for TV Testing

Detail produk:

Tempat asal:	CINA
Nama merek:	Haida
Sertifikasi:	CE,,ISO
Nomor model:	9003-HD

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Setiap set dilindungi dengan serat resin dan film PP, kemudian dimasukkan ke dalam kasing kayu yang
Waktu pengiriman:	20 hari setelah pesanan dikonfirmasi
Syarat-syarat pembayaran:	L/C, T/T, D/A, D/P, Western Union, Moneygram
Menyediakan kemampuan:	300 set per bulan

Kontak

Standard and High-Definition Video Formats Charge / Discharge Battery Testing System for TV Testing

Deskripsi

Aplikasi:	Pengujian Baterai	Metode kabel:	AC empat fase empat fase
Menampilkan:	LCD	Kisaran saat ini:	0-10A
Resolusi:	0.001V/0.001a	Metode kabel:	AC 220V
Ketepatan:	± 0,1%	Catu daya:	Ac
Menyoroti:	Standard Charge Discharge Battery Testing System , High Definition Charge Discharge Battery Testing System

Detailed Product Information
- Place of Origin: China
- Brand Name: Kingpo
- Certification: ISO9001, CE
- Model Number: 8280
- Weight: 2 kg
- Dimensions: 290×270×60 mm (L×W×H)
- Power Supply: 220 VAC, 50 Hz
- Compliance Standards: IEC 60065
- Channel Options: 0° or 90° phase shift
- Reference Frequency: 1000 Hz
- Application: TV test equipment, audio signal testing
Product Overview
This Pink Noise Generator is designed to meet the pink noise specifications outlined in IEC 60065 (Clauses 4.2 and 4.3) and IEC 62368-1 (Annex E). It is ideal for evaluating tone frequency amplifiers, particularly when dual-channel or 90° phase-shift output is required.

Key Features

Output options: pink noise or 1000 Hz sine wave (selectable, not simultaneous)
Dual output channels with configurable phase shift (0° or 90°)
Adjustable output voltage with fine-tuning capability
Multiple connector types: RCA and 4 mm banana jacks
Includes test cables: RCA and 3.5 mm phono connectors
Complies with IEC 60065 Annex C, Figure C1 (IEC 60268)

Output Voltage Ranges

Level	Sine Wave (1 kHz)	Filtered Pink Noise (RMS)
Low	0–100 mV / 1 kΩ	0–35 mV / 1 kΩ
Medium	0–1 V / 1 kΩ	0–350 mV / 1 kΩ
High	0–5 V / 1 kΩ	0–1.7 V / 1 kΩ
